Advantage

Devoted to High Reliability
Over 15 years of in-house fabrication and expertise ensure your PCBs are made to last. 100% quality guaranteed or we’ll remake them free of charge.
Full-Feature Turnkey PCBA
PCB manufacture and Turnkey PCB assembly (PCBA) under one roof with mature global supply chain and parts sourcing capabilities.
99.6% On-Time Delivery Rate
Speed up your workflow with competitive delivery times. PCBs can be manufactured in as little as 24 hours. Various shipping options are available.
Superior One-on-One Service
Get peace of mind with one-on-one assistance from your dedicated account manager and tailored enterprise services.

Single/Double sided PCB

Single-Sided PCB refers to a circuit board with only one side covered with copper for circuit layout and soldering components, and the other side does not have any copper or electrical connection.

Double-Sided PCB refers to a circuit board with copper on both sides for circuit layout and soldering components. This design allows for more complex circuit wiring.

Advantages of 1L 2L PCB

At KINGFIELD, standard PCB services refer to full-featured printed circuit board manufacturing services. With over 10 years of PCB manufacturing experience, we have handled hundreds of thousands of PCB projects and covered almost all types of substrate materials, including FR4, Aluminum, Rogers, etc.

Short production cycle
The manufacturing process is relatively simple, the production cycle is short, and it is suitable for rapid prototyping.
High reliability
Since there is only one side with circuits, the possible via problems are reduced, and the reliability is high.
Flexible wiring scheme
Both sides can be used for wiring, the design is more flexible, and the wire length can be effectively reduced to improve electrical performance. Reduce the size of the circuit board: Higher wiring density allows more components and connections to be accommodated in a smaller area, which is suitable for miniaturized design.
Reduce the size of the circuit board
Higher wiring density allows more components and connections to be accommodated in a smaller area, which is suitable for miniaturized design.

Production Capacity

Items

Rigid

Material

Lead-free、Halogen-free、H-Tg、Low loss

Layers

1-40L

Max cut lamination size

Min3*3mm-Max1200mm

Final board thickness

0.18-5.0mm

Min Final Hole size

0.075mm

Aspect Ratio

14:1

Inner layer Line Width/Space

0.05mm

Copper Foil Thickness (Inner Layers)

1/2oz~3.0oz

Min dielectric layer thickness

50um

Copper Foil Thickness (Outer Layers)

Hoz-14oz

Copper to drill distance

0.2mm

Out layer Line width/space

0.05mm

Min SMD width

0.05mm

Max Solder Mask Plug Hole Diameter

0.5mm

solder mask strip width

0.075mm（Green/1OZ）

Final Set Size Tolerance

±0.1mm/limit±0.05mm

Min Hole to  board edge Distance

0.15mm

Min Beveling angle Tolerance

±3-5°

Layer to layer Tolerance

≤0.075mm(1-6L）

Inner layer Min PTH Annular Ring

0.15mm

Out layer Min PTH Annular ring

0.15mm

Surface Treatment

OSP、HASL 、ENIG、Gold Finger、Plating Gold 、ENEPIG、IMM TIN、IMM AG

Warp&Twist

≤0.5%

Home electronics
Consumer
Communication
Industrial
